• Wide Input Voltage Range: 4.5V to 32V
• Output Voltage Range: 0.613V to 5.5V
• Wide Output Load Range: 0A to 7A
• Built-In 1% 0.613V Reference
• Built-In LDO Linear Voltage Regulator
• RCOT_TM (Robust Constant On-Time) Control Architecture
• 4 Selectable Frequency Setting
• 4700ppm/°C R_DS(ON) Current Sensing
• 0.6ms, 1.2ms, 2.4ms and 4.8ms Selectable Internal Voltage Soft-Start
• Pre-charged Start-up Capability
• Built-in Output Discharge
• Built-in OVP/UVP/OCP/OTP
• WQFN4x4-32L Package
• RoHS Compliant and Halogen Free

Application

• Portable Charging Devices
• Point-of-Load Systems
• Notebook Computers
• I/O Supplies
• System Power Supplies
