Feature

• Wide Input Voltage Range : 10.8V to 32V.
• Input Voltage Absolute Maximum Rating: 36V.
• Up to 2.3A Output Current.
• CV/CC Mode Control (Constant Voltage and Constant Current).
• Automatic Selection of D+/D- Mode for an Attached Device
• Apple Mode: D+/D- Divider Mode 2.7V and 2.7V.
• Short Mode: BC 1.2DCP Mode.
• Samsung Mode: D+/D- Divider Mode 1.2V and 1.2V.
• Internal QC2.0 and FCP.
• Output Constant Voltage: 5.2V/9.2V/12.3V.
• Output Voltage Accuracy: ±2%
• Fixed 125kHz Frequency Operation.
• Up to 95% Conversion Efficiency.
• Internal Soft Start: 10ms.
• Fixed Cable Compensation Voltage.
• Adjustable External CC (Constant Output Current) Limit Setting: Default = 2.3A.
• CC (Constant Output Current) Limit Accurarcy:±3%.
• Short Circuit Protection.
• VIN/VOUT Over Voltage Protection and Over Temperature Protections.
• VDFN6x5-8L Package.
• RoHS Compliant and Halogen Free.

Application

• PDA Like Device Car Chargers.
• Portable Charging Devices.
